Active System Integration

1/3″ 4Megapixel progressive scan Image Sensor
H.264 & MJPEG dual-stream encoding
Max15fps@4M and 25/30fps@1080P
Day/Night(electronic), 3D-DNR, AWB, AGC, BLC
Multiple adjust mode: original image, panorama, double panorama, 1 3 mode, single window EPtz, 4 window split model
1.18mm fixed lens
Supports PoE, IK10, SD Card
Mobile Software: iCMOB, gCMOB
CMS Software: KVMS Pro, vOptimus Pro

1/3″ 4Megapixel progressive scan Image Sensor
H.264 & MJPEG dual-stream encoding
Max15fps@4M and 25/30fps@1080P
Day/Night(electronic), 3D-DNR, AWB, AGC, BLC
Multiple adjust mode: original image, panorama, double panorama, 1 3 mode, single window EPtz, 4 window split model
1.18mm fixed lens
Supports PoE, IK10, SD Card
Mobile Software: iCMOB, gCMOB
CMS Software: KVMS Pro, vOptimus Pro

Image Sensor1/3" 4Megapixel progressive scan CMOS

Minimum Illumination0.01lux/F2.0(color) ,0.001Lux@F2.0(B/W)

Shutter SpeedAuto/Manual 1/3(4)~1/100000

White BalanceAuto/Manual

Lens1.18mm

AGC ControlAuto/Manual

Video CompressionH.264/MJPEG

S/N RatioMore than 50 dB

Video StreamingMain Stream:4M(1~15fps)/ 3M (1 ~ 25/30fps), Extra Stream: D1/CIF(1 ~ 25fps)

Resolution4M(2592x1520)/3M(2048x 1520)/UXGA(1600x 1200)/1.3M(1280x 960)/720P(1280x 720)/D1(704x 576/704x 480)/CIF(352x 288/352x 240)

ICRAuto(electronic)/Color/B/W

Audio Input1 Ch.

Audio Output1 Ch.

Audio ComprerssionG.711a/G.711u/PCM

Alarm IN1 Ch

Alarm Out1 Ch

Interface1 RJ45

ProtocolHTTP,TCP,ARP,RTSP,RTP,UDP,RTCP,SMTP,FTP,DHCP,DNS, DDNS,PPPOE,IPv4/v6,SNMP,QoS,UPnP,NTP, Onvif Profile S

Smart PhoneiPhone, iPad, Android Phone

Micro SDMicro SD, Max 64GB

Operating Temperature-30°C~+60°C, Less than 95% RH

Power SourceDC12V, PoE(802.3af)

Power ConsumptionMax 6W

Weatherproof StandardIK10

DimensionΦ110mm×54mm

Weight0.25kg
