COSEC ARC DC100P

Choose the best products in our company
Home / Matrix / Access Control /  COSEC ARC DC100P
matrix

COSEC ARC DC100P


Specification

  • Superior Design which Enhances the Look of your Premises
  • Better Capacity
  • Select Credential as per Requirement
  • Convenient Operation and Installation
  • Ideal for Network Mode Solution at Multiple Locations
  • Various Interfaces to Control Various Applications
  • 4.3" Touch-screen Capacitive Display
  • Fingerprint, RFID Card and PIN
  • Proximity and Smart Cards
  • EM Prox, HID Prox, Mifare and HID iCLASS

COSEC DOOR FMX

In the fast-paced evolution of technology, organizations have started adapting the biometric application systems for access control and time-attendance. This technology has enabled organizations to enhance security within their premises and organized the process of time-attendance and access control. Compared to the traditional biometric readers scanning a single layer of skin, multispectral biometric attendance system employs multi-layered reading. Matrix COSEC DOOR FMX is a high-performance door controller with multispectral sensor technology. It reads both - the surface and the subsurface of a finger producing more accurate image even when the finger surface features are difficult to read due to dirt, usage, age or tough environmental conditions. Powered by a high-speed processor and fingerprint detection algorithm, DOOR FMX is specifically engineered for high security applications including Defense, Airports, R&D Labs, Banks and Industries such as Mining, Construction and Heavy Manufacturing for their access control and time-attendance needs. COSEC DOOR FMX offers significantly lesser False Acceptance Ratio (FAR) and False Rejection Ration (FRR) making it ideal for both - high-security and harsh industrial applications. This unique identification process outperforms all other fingerprint sensors and offers robust and reliable biometric information of the user. DOOR FMX is a perfectly tailored product with 4.3" touch screen display and multiple connectivity options in a compact and elegant design. This makes it ideal for any Time-Attendance System and Access Control applications. Based on powerful processor, DOOR FMX supports 500,000 events storage and 50,000 users in its memory, making it ideal even for large organizations with heavy and continuous flow of people. With intuitive user interface TFT LCD display, DOOR FMX supports all time-attendance, access control and enrollment functions. It is simple to install and operate with multiple connectivity options and wall mounting. When used with COSEC, DOOR FMX can work various applications such as Access Control, Job Processing and Costing, Time-Attendance, Contract Workers Management, Visitor Management, Cafeteria Management, Vehicle Access Management and others.

Model COSEC DOOR FMX
GENERAL
Credential Support Fingerprint, RFID Card and PIN
Display 4.3" Capacitive Touch Screen
User Capacity 1000 (1:N) and 50,000 (1:1)*
Template Capacity 1000 (1:N) and 100,000 (1:1)
Cards Per User Up to 2
Types of Cards Support EM Prox, HID Prox, HID iClass and Mifare (COSEC CPM Module Required)
Event Buffer 500,000
Communication Ethernet, PoE, Wi-Fi and Mobile Broadband (3G/4G)
Exit Switch Yes
Door Status Sense Programmable NO, NC and Supervised
Door Lock Relay Form C and SPDT Relay (Max 2A@30 VDC)
Door Lock Power 12VDC @ 1A (for Adaptor Supply Mode) 12VDC @ 0.5A (For PoE Supply Mode)
Aux-IN Programmable NO, NC and Supervised
Aux-OUT Form C and SPDT Relay (Max 2A@30 VDC)
Reader Interface types RS 232 and Wiegand In Only
USB 2 (1 for Data Transfer and 1 for Broadband Dongle)
CPU 800 MHz ARM Cortex A8 based Processor
Flash Memory 256MB Flash
RAM Memory 512 MB DDR3 RAM
Micro SD Card Yes (Inbuilt 4 GB)
Input Power 12VDC @ 2A
Battery Backup No Internal Battery Backup and External through Power Supply Battery Backup (PSBB)
Weight 0.6kg (1.32 lbs)
Humidity 5% to 85% RH Non-condensing
Operating Temperature 0°C to + 50°C (32°F to 122°F)
System Integration API for Software Integration
Operational Mode Direct Door with COSEC CENTRA Server
Tamper Detection Yes
System Integration API for Software Integration
Sensor Technology Multispectral Lumidigm Sensor with LFD
Sensing Area 27mm x 30mm x 41mm
