Active System Integration

1/1.8″ 6 Megapixel PS CMOS Image Sensor
H.264 & MJPEG dual-stream encoding
Max 25/30fps@6.0M(3072×2048)
DWDR, Day/Night(ICR), 3DNR, ROI, AWB, AGC, BLC
Multiple De-wrap Mode: Original ,Panoramic, Double Panoramic,1 3,Eptz,4 pictures
IR Range of 10 Mtr.
Supports PoE, Micro SD Card, IP67, IK10
Mobile Software: iCMOB, gCMOB
CMS Software: KVMS Pro, vOptimus Pro

1/1.8″ 6 Megapixel PS CMOS Image Sensor
H.264 & MJPEG dual-stream encoding
Max 25/30fps@6.0M(3072×2048)
DWDR, Day/Night(ICR), 3DNR, ROI, AWB, AGC, BLC
Multiple De-wrap Mode: Original ,Panoramic, Double Panoramic,1 3,Eptz,4 pictures
IR Range of 10 Mtr.
Supports PoE, Micro SD Card, IP67, IK10
Mobile Software: iCMOB, gCMOB
CMS Software: KVMS Pro, vOptimus Pro

Image Sensor1/1.8" 6Megapixel CMOS

Minimum Illumination0.01Lux/F2.0(Color), 0Lux/F2.0(IR on)

Shutter SpeedAuto/Manual, 1/3~1/100000s

White BalanceAuto/Manual

Lens1.55mm

AGC ControlAuto/Manual

Video CompressionH.264H/H.264/MJPEG/JPEG

S/N RatioMore than 50 dB

Back Light Comp.BLC/ HLC/ DWDR

Video StreamingMain Stream:6M/(1 ~ 25/30fps), Extra Stream: D1/CIF(1 ~ 25fps)

Resolution6M(3072×2048)/3M(2048×1536)/1080P(1920×1080)

ICRAuto(ICR)/Color/B/W

Audio Input1 Ch.

Audio Output1 Ch.

Audio ComprerssionG.711a/G.711u/PCM

Alarm IN2 Ch.

Alarm Out1 Ch.

Interface1 RJ45

ProtocolHTTP,TCP,ARP,RTSP,RTP, UDP,RTCP,SMTP,FTP,DHCP,DNS,DDNS,PPPOE, IPv4/v6,SNMP,QoS,UPnP,NTP, Onvif, PSIA CGI

Smart PhoneiPhone, iPad, Android Phone

Micro SDMicro SD, up to 64GB

Operating Temperature-30°C~+60°C, Less than 95%RH

Power SourceDC12V, PoE(802.3at)

Power Consumption<11W

Weatherproof StandardIP67, IK10

DimensionΦ150mm x 50.7mm

Weight0.58kg(0.86kg with packaging )
