- 4 Ch. with 1080p Realtime Live View
- H.264/MJPEG dual codec decoding
- Max 24Mbps incoming bandwidth
- Support 1 SATA HDDs up to 4TB, 2 USB2.0
- HDMI / VGA simultaneous video output
- Support Multi-brand network cameras, Support P2P (QR code Scan)
- ONVIF Version 2.4 conformance
- Mobile Software: iCMOB, gCMOB, wCMOB
- CMS Software: KVMS, KVMS Pro
ProcessorDual-core embedded processor
Operating SystemEmbedded LINUX
IP Camera Input4 channel
User InterfaceGUI
Video Output1 HDMI, 1 VGA
CompressionH.264 / MJPEG
Video Resolution1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Motion DetectionMD Zones: 396(22×18).
Video Losssupports
Camera Blanksupports
Hard Disk1 SATA ports, up to 4TB
Smart PhoneiPhone, iPad, Android, Windows Phone
Trigger EventsRecording, PTZ, Tour & Screen
Recording ModeManual, Schedule(Regular(Continuous), MD, Alarm), Stop
Search ModeTime/Date, Alarm, MD & Exact search (accurate to second), Smart search
PlaybackPlay, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection,Digital zoom
Backup ModeUSB Device / Internal SATA burner/ Network
Interface Ports1 HDMI, 1 VGA, 2 USB2.0, 1 RJ45
Record Interval1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Max User Account128 users
Ethernet1 RJ-45 port (10/100M)
ProtocolsHTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter,PPPOE, DDNS, FTP, Alarm Server,ONVIF Version 2.4
Power Supplysingle, DC12V/2A
Power Consumption<2W (without HDD)
Working Temp-10 ~+55°C / 10~90%RH / 86~106kpa
Dimension192mm×128mm×36mm
Weight320g (without HDD)
